Product Code: PRG-RCS
| Tank Structure | up to 20.000 lt |
| Jetting Pump | up to 400 bars, 400 lpm |
| Vacuum Pump Type | Rotary Vane, Blower or Liquid Ring |
| Vacuum Capacity | up to 12.000 m³/h free air |
| Pump Drive | PTO or Hydraulic |
| Hydraulic Hose Reel | Fixed or Rotating, with speed adjutment, up to 120m hose |
| Auxiliary Hose Reel | Manual or hydraulic , up to 80m hose |
| Operation | Control panel, automation, radio remote control, touchscreen |
| Suction Boom | Arm boom or Mobile Arm Reel - up to 20m hose capacity |
Recycling units can operate continuously for a long time, without any water supply, and clean sewer lines with reduced water flow. The system, they are equipped with, allows them to mass the sludge and transport solid material containing small percentages of water. The system is self-cleaning. The equipment can work anytime and automatically as a standard COMBI.
Recycling System: Dirty water is pumped by the roll round pump, through the 1st filter, which separates bigger particles, to the 2nd cyclone filter, where the dirty water is cleaned. Contaminated water and its particles, are led back to the sludge chamber, at the exit side of the dirty water. There will be also an activating valve that can maintain the constant pressure in the 2nd cyclone filter. In the end, cleaned water is transported to the clean water chamber for jetting purposes. The filtering is affected by the rotating slot screen drum. A scraper system keeps the drum free of clogging.
